| ITEM | DESCRIPTION |
|---|---|
| MATERIAL: | PVC + NYLON (V0) |
| THICKNESS: | 0.35 mm |
| COLOR: | BLACK + SILVER GREY |
| SURFACE RESISTANCE: | 4.0 × 10¹¹Ω |
| FUNCTIONS: | PROVIDES PROTECTION AND A CLEAN APPEARANCE FOR WIRING, EASY TO REMOVE AND FULLY REUSABLE. |
| USAGE: | DESIGNED FOR THE PROTECTION OF BRANCHED CABLE ASSEMBLIES. |
| ITEM | TRANSVERSE | LONGITUDINAL |
|---|---|---|
| TEAR STRENGTH: | 65.7 N | 56.3 N |
| TENSILE STRENGTH: | 727 N | 921 N |
| ELONGATION: | 22% | 20% |
| MODEL | WIDTH (mm) | DIAMETER (mm) | LENGTH | PACKAGING |
|---|---|---|---|---|
| YB-BG-10 | 62 | Φ10 | 50 M | PAPER BOX |
| YB-BG-15 | 75 | Φ15 | ||
| YB-BG-20 | 90 | Φ20 | ||
| YB-BG-25 | 105 | Φ25 | ||
| YB-BG-30 | 120 | Φ30 | ||
| YB-BG-40 | 150 | Φ40 | ||
| YB-BG-50 | 180 | Φ50 | ||
| YB-BG-70 | 242 | Φ70 | ||
| YB-BG-100 | 335 | Φ100 |
